Pressure Gauge Brass & Steel Bottom Entry Dry 40-100 Series 1/4" NPT 100mm 400psi

Features

• Clear front plexiglass lenses on all models except the 4\\ 105 and 115 models, which utilises a bayonet ring
• Single-piece machined brass stem and connection
• High quality bourdon tubes
• 'C' configuration bourdon tubes on pressure ranges of 600psi and lower and 'coiled/spiral' tubes on ranges above 600psi
• Spiral tube allows the higher pressure to be spread out over a greater area reducing tube stress
• Accurate readings to a standard ±2.5% of full-scale tolerance (higher accuracies are available)
• Standard dials are UV resistant and dual scale in psi and kPa
• Steel case, dry
• Port size: 1/4\\ NPT
• Diameter: 100mm
• Pressure: 400psi (2,560kPa)

Suitable For

• Applications in pneumatics, hydraulics, petrochemical, medical, food and most industrial and commercial applications
