Pressure Gauge Stainless Steel Bottom Entry Liquid Filled 40-400 Series 1/2" NPT 100mm 2000psi

Name: Pressure Gauge Stainless Steel Bottom Entry Liquid Filled 40-400 Series 1/2" NPT 100mm 2000psi
Brand: atom
SKU: 7312006
Availability: InStock

SKU: 7312006 MPN: 40-400-2000

Sale Sold out

Shipping calculated at checkout.

Quantity

Liquid filled stainless steel pressure gauge for various industrial applications

View full details

UNSPSC	41112412

Features

All stainless steel construction for ultimate corrosion resistance
Available with trogamide, instrument glass or laminated safety glass
Argon arc welded connection and bourdon tubes to maintain the integrity of the measuring system
'C' configuration tubes on pressure ranges of 600psi and lower and 'coiled/spiral' tubes on ranges above 600psi
Stainless steel precision movements and balanced pointers for smooth, accurate indication
Liquid filled
Diameter: 100mm
Bottom entry
Port size: ½\\ NPT
Pressure: 2,000psi (12,160kPa)

Suitable For

Applications in chemical, pharmaceutical, food and beverage, offshore, papermills, salt mines and agricultural industries
